PE Layflat Hose
PE Layflat Hose
PE layflat hose, also known as polyethylene layflat hose, is a type of flexible hose made from high-density polyethylene (HDPE) material.It is designed for water transfer applications, such as irrigation, dewatering, and general water discharge.
Construction:
Lining:PE
Reinforcement Cover:Polyester jacket
Temperature:-40℃ to +80℃ ( -40℉ to +176℉ )
PE Layflat Hose Feature
●Made of non-toxic and recyclable materials, polyethylene.
●Anti-crossing and anti-aging, shelf life for more than 10 years.
●High tensile strength and high impact resistance.
●Flexible and easy to carry and install in the filed, low coat, cost saving.
●Anti -ultraviolet radiation ,prolong life.
● Working pressure:8bar,10bar,13bar,16bar,20bar,25bar
PE Layflat Hose Specification
| ID | Wall Thinckness | W.P. | B.P. | l | kg | kg | m3 |
| mm | mm | bar | bar | m | g | kg | cm |
| 32 | 0.4 | 3 | 9 | 100 | 49 | 4.9 | 46*6*46 |
| 40 | 0.4 | 3 | 9 | 100 | 57 | 5.7 | 46*7*46 |
| 50 | 0.6 | 3 | 9 | 100 | 99 | 9.9 | 53*9*53 |
| 63 | 0.4 | 2.5 | 7.5 | 100 | 82 | 8.2 | 46*11*46 |
| 63 | 0.6 | 3 | 9 | 100 | 116 | 11.6 | 53*11*53 |
| 75 | 0.4 | 2 | 6 | 100 | 94 | 9.4 | 46*13*46 |
| 75 | 0.6 | 2.5 | 7.5 | 100 | 134 | 13.4 | 53*13*53 |
| 90 | 0.4 | 2 | 6 | 100 | 111 | 11.1 | 46*15*46 |
| 90 | 0.6 | 2.5 | 7.5 | 100 | 152 | 15.2 | 53*15*53 |
| 100 | 0.75 | 2.5 | 7.5 | 100 | 208 | 20.8 | 59*17*59 |
| 110 | 0.6 | 2 | 6 | 100 | 187 | 18.7 | 53*19*53 |
| 152 | 0.75 | 1.5 | 4.5 | 100 | 296 | 29.6 | 59*25*59 |
PE Lay flat Hose Application
PE layflat hose is used for shallow root row crops( strawberries,tomatoes, broccoli, celery, tomatoes, vegetables, etc,);Deep-rotted row crops(watermelon, grape, cantaloupe, zucchini, pepper,etc); Perennial planting crops (tobacco, asparagus, lily flower,papaya, banana,etc); edible fungus, cotton, nursery, flowers, filed crops, desert afforestation;suitable for greenhouse cultivation.
