Long Distance Water Supply Hose
Long Distance Water Supply Hose
A Long Distance Water Supply Hose is a type of hose that can be flatly coiled for positive-pressure conveyance. It is made by co-extruding TPU or rubber inner layer, fiber reinforcement layer, and TPU or rubber outer layer in a single molding process.
Construction:
Material: High-quality polyurethane inside and outside, and high-strength polyester yarn in the middle layer.
Length: 100m/roll
Size: 4”-6”
Working pressure: 28BAR-40BAR
Burst pressure: ≥84BAR-120BAR
Optional lining: Special rubber
Optional structure: Double sided
Custom process: Adding fluorescent strips
Standard color: Red(Other colors can be customized)
Long Distance Water Supply Hose Feature
- Advanced one-time co-extrusion molding process
- 3 times the safety factor, 1.5 times the factory pressure test high-quality raw materials, stable performance
- Abundant supporting facilities, easy to use and easy to maintain
- Light weight, high pressure bearing, high conveying efficiency
- Soft texture, rollable, easy to operate
- Strong environmental adaptability, safe and reliable use, durable
Long Distance Water Supply Hoses Specification
Inner Diameter | Working Pressure | Burst Pressure | Weight | Wall Thickness | Tensile Strength | ||||||
Inch | mm | Psi | Bar | Psi | Bar | Lbs/ft | Kg/m | Inch | mm | Lbs | Kg |
6 | 152 | 150 | 10 | 450 | 30 | 0.92 | 1.37 | 0.12 | 3 | 37478 | 17000 |
8 | 203 | 150 | 10 | 450 | 30 | 1.65 | 2.45 | 0.14 | 3.9 | 63784 | 31200 |
10 | 254 | 150 | 10 | 450 | 30 | 2.17 | 3.22 | 0.16 | 4 | 85258 | 38673 |
12 | 300 | 150 | 10 | 450 | 30 | 4.03 | 4.5 | 0.17 | 4.2 | 107304 | 45673 |
16 | 400 | 150 | 8 | 360 | 24 | 4.96 | 7.38 | 0.20 | 5.1 | 147150 | 66747 |
Long Distance Water Supply Hoses Schematic Diagram
![Remote Water Supply Hose schematic diagram Remote Water Supply Hose schematic diagram](https://stronglayflathose.com/wp-content/uploads/2023/06/Remote-Water-Supply-Hose-schematic-diagram.jpg)
Application
Widely used in urban emergency water supply and drainage systems (firefighting, water pollution, floods, etc.), it can quickly realize the supply and drainage problems in emergency situations.
![Long Distance Water Supply Hose application Long Distance Water Supply Hose application](https://stronglayflathose.com/wp-content/uploads/2023/06/Long-Distance-Water-Supply-Hose-application.jpg)
