Double Jacket Fire Hose
Double Jacket Fire Hose
Double jacket fire hose consists of two layers of woven synthetic fabric, typically made of polyester or nylon, which are wrapped around a rubber inner liner. which provide added durability and strength compared to a single jacket hose.
Construction:
Lining:PVC,PU,Rubber lining
Reinforcement Cover:Double Polyester jacket
Working pressure:10bar,13bar,16bar,20bar,25bar
Custom: color,length,printing,working pressure,couplings
Double Jacket Fire Hose Feature
● High pressure resistance
● High Abrasion resistance
● Low-temperature resistance
● Ozone resistance, Long service life.
Double Jacket Hose Specification
| I.D. | W.P. | B.P. | Length | |||
| inch | mm | Bar | Mpa | Bar | Mpa | m |
| 1" | 25 | 10-25 | 1.0-2.5 | 30-75 | 3.0-7.5 | 40 |
| 1-1/4" | 32 | 10-25 | 1.0-2.5 | 30-75 | 3.0-7.5 | 40 |
| 1-1/2" | 38 | 10-25 | 1.0-2.5 | 30-75 | 3.0-7.5 | 40 |
| 1-3/4" | 45 | 10-25 | 1.0-2.5 | 30-75 | 3.0-7.5 | 40 |
| 2" | 51 | 10-25 | 1.0-2.5 | 30-75 | 3.0-7.5 | 40 |
| 2-1/2" | 64 | 10-25 | 1.0-2.5 | 30-75 | 3.0-7.5 | 40 |
| 2-3/4" | 70 | 10-25 | 1.0-2.5 | 30-75 | 3.0-7.5 | 40 |
| 3" | 76 | 10-25 | 1.0-2.5 | 30-75 | 3.0-7.5 | 40 |
| 4" | 102 | 10-25 | 1.0-2.5 | 30-75 | 3.0-7.5 | 40 |
| 5" | 127 | 10-25 | 1.0-2.5 | 30-75 | 3.0-7.5 | 40 |
| 6" | 152 | 10-25 | 1.0-2.5 | 30-75 | 3.0-7.5 | 40 |
Double Jacket Hose Application
It is designed for Fire-fighting,Shipping, petroleum,Chemical industry, Agriculture, Mining.It serves as a vital link between fire hydrants or water sources and firefighting equipment, such as fire engines, pumps, or nozzles. The hose’s ability to withstand high pressure and deliver a steady flow of water makes it invaluable in extinguishing fires effectively. Whether in urban or rural settings, industrial sites, residential areas, or wildland firefighting, the double jacket fire hose is an indispensable tool for first responders.
